GE af-600 fp User Manual

Illustration 5.22: Terminal in details
NB!
Power connections can be made to positions A or B
5.3.5 Terminal Locations - Unit Sizes 6X
Terminal locations - Unit Sizes 61 and 63
Illustration 5.23: Terminal locations - Inverter Cabinet - 61 and 63 (front, left and right side view)
1) Ground bar
2) Motor terminals
3) Brake terminals
AF-600 FP High Power Operating Instructions
57
5
