Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
PC-0# PC-00 Pump Controller [0] Disabled 2 set-ups FALSE - Uint8 PC-02 Motor Start [0] Direct on Line 2 set-ups FALSE - Uint8
PC-04 Pump Cycling [0] Disabled All set-ups TRUE - Uint8
PC-05 Fixed Lead Pump [1] Yes 2 set-ups FALSE - Uint8
PC-06 Number of Pumps 2 N/A 2 set-ups FALSE 0 Uint8
PC-1# PC-2# PC-20 Staging Bandwidth 10 % All set-ups TRUE 0 Uint8 PC-21 Override Bandwidth 100 % All set-ups TRUE 0 Uint8 PC-22 Fixed Speed Bandwidth casco_staging_bandwidth (P2520) All set-ups TRUE 0 Uint8
PC-23 SBW Staging Delay 15 s All set-ups TRUE 0 Uint16
PC-24 SBW Destaging Delay 15 s All set-ups TRUE 0 Uint16
PC-25 OBW Time 10 s All set-ups TRUE 0 Uint16
PC-26 Destage At No-Flow [0] Disabled All set-ups TRUE - Uint8
PC-27 Stage Function [1] Enabled All set-ups TRUE - Uint8
PC-28 Stage Function Time 15 s All set-ups TRUE 0 Uint16
PC-29 Destage Function [1] Enabled All set-ups TRUE - Uint8
PC-3# PC-30 Destage Function Time 15 s All set-ups TRUE 0 Uint16 PC-4# PC-40 Decel Ramp Delay 10.0 s All set-ups TRUE -1 Uint16 PC-41 Accel Ramp Delay 2.0 s All set-ups TRUE -1 Uint16
PC-42 Staging Threshold ExpressionLimit All set-ups TRUE 0 Uint8
PC-43 Destaging Threshold ExpressionLimit All set-ups TRUE 0 Uint8
PC-44 Staging Speed [RPM] 0 RPM All set-ups TRUE 67 Uint16
PC-45 Staging Speed [Hz] 0.0 Hz All set-ups TRUE -1 Uint16
PC-46 Destaging Speed [RPM] 0 RPM All set-ups TRUE 67 Uint16
PC-47 Destaging Speed [Hz] 0.0 Hz All set-ups TRUE -1 Uint16
PC-5#
PC-50 Lead Pump Alternation [0] Off All set-ups TRUE - Uint8 PC-51 Alternation Event [0] External All set-ups TRUE - Uint8 PC-52 Alternation Time Interval 24 h All set-ups TRUE 74 Uint16
PC-53 Alternation Timer Value 0 N/A All set-ups TRUE 0 VisStr[7]
PC-54 Alternation Predefined Time ExpressionLimit All set-ups TRUE 0
TimeOfDay-
WoDate
PC-55 Alternate if Load < 50% [1] Enabled All set-ups TRUE - Uint8
PC-56 Staging Mode at Alternation [0] Slow All set-ups TRUE - Uint8
PC-58 Run Next Pump Delay 0.1 s All set-ups TRUE -1 Uint16
PC-59 Run on Line Delay 0.5 s All set-ups TRUE -1 Uint16
PC-8#
PC-80 Pump Status 0 N/A All set-ups TRUE 0 VisStr[25] PC-81 Pump Status 0 N/A All set-ups TRUE 0 VisStr[25] PC-82 Lead Pump 0 N/A All set-ups TRUE 0 Uint8
PC-83 Relay Status 0 N/A All set-ups TRUE 0 VisStr[4]
PC-84 Pump ON Time 0 h All set-ups TRUE 74 Uint32
PC-85 Relay ON Time 0 h All set-ups TRUE 74 Uint32
PC-86 Reset Relay Counters [0] Do not reset All set-ups TRUE - Uint8
PC-9#
PC-90 Pump Interlock [0] Off All set-ups TRUE - Uint8 PC-91 Manual Alternation 0 N/A All set-ups TRUE 0 Uint8
7.2.22 PC-## Pump Controller
AF-600 FP High Power Operating Instructions
146
