Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
XC-0# XC-00 Closed Loop Type [0] Auto 2 set-ups TRUE - Uint8 XC-01 PID Performance [0] Normal 2 set-ups TRUE - Uint8
XC-02 PID Output Change 0.10 N/A 2 set-ups TRUE -2 Uint16
XC-03 Minimum Feedback Level -999999.000 N/A 2 set-ups TRUE -3 Int32
XC-04 Maximum Feedback Level 999999.000 N/A 2 set-ups TRUE -3 Int32
XC-09 PID Autotuning [0] Disabled All set-ups TRUE - Uint8
XC-1#
XC-10 Ext. 1 Ref./Feedback Unit [1] % All set-ups TRUE - Uint8 XC-11 Ext. 1 Minimum Reference 0.000 ExtPID1Unit All set-ups TRUE -3 Int32 XC-12 Ext. 1 Maximum Reference 100.000 ExtPID1Unit All set-ups TRUE -3 Int32
XC-13 Ext. 1 Reference Source [0] No function All set-ups TRUE - Uint8
XC-14 Ext. 1 Feedback Source [0] No function All set-ups TRUE - Uint8
XC-15 Ext. 1 Setpoint 0.000 ExtPID1Unit All set-ups TRUE -3 Int32
XC-17 Ext. 1 Reference [Unit] 0.000 ExtPID1Unit All set-ups TRUE -3 Int32
XC-18 Ext. 1 Feedback [Unit] 0.000 ExtPID1Unit All set-ups TRUE -3 Int32
XC-19 Ext. 1 Output [%] 0 % All set-ups TRUE 0 Int32
XC-2#
XC-20 Ext. 1 Normal/Inverse Control [0] Normal All set-ups TRUE - Uint8 XC-21 Ext. 1 Proportional Gain 0.01 N/A All set-ups TRUE -2 Uint16 XC-22 Ext. 1 Integral Time 10000.00 s All set-ups TRUE -2 Uint32
XC-23 Ext. 1 Differentation Time 0.00 s All set-ups TRUE -2 Uint16
XC-24 Ext. 1 Dif. Gain Limit 5.0 N/A All set-ups TRUE -1 Uint16
XC-3#
XC-30 Ext. 2 Ref./Feedback Unit [1] % All set-ups TRUE - Uint8 XC-31 Ext. 2 Minimum Reference 0.000 ExtPID2Unit All set-ups TRUE -3 Int32 XC-32 Ext. 2 Maximum Reference 100.000 ExtPID2Unit All set-ups TRUE -3 Int32
XC-33 Ext. 2 Reference Source [0] No function All set-ups TRUE - Uint8
XC-34 Ext. 2 Feedback Source [0] No function All set-ups TRUE - Uint8
XC-35 Ext. 2 Setpoint 0.000 ExtPID2Unit All set-ups TRUE -3 Int32
XC-37 Ext. 2 Reference [Unit] 0.000 ExtPID2Unit All set-ups TRUE -3 Int32
XC-38 Ext. 2 Feedback [Unit] 0.000 ExtPID2Unit All set-ups TRUE -3 Int32
XC-39 Ext. 2 Output [%] 0 % All set-ups TRUE 0 Int32
XC-4#
XC-40 Ext. 2 Normal/Inverse Control [0] Normal All set-ups TRUE - Uint8 XC-41 Ext. 2 Proportional Gain 0.01 N/A All set-ups TRUE -2 Uint16 XC-42 Ext. 2 Integral Time 10000.00 s All set-ups TRUE -2 Uint32
XC-43 Ext. 2 Differentation Time 0.00 s All set-ups TRUE -2 Uint16
XC-44 Ext. 2 Dif. Gain Limit 5.0 N/A All set-ups TRUE -1 Uint16
XC-5#
XC-50 Ext. 3 Ref./Feedback Unit [1] % All set-ups TRUE - Uint8 XC-51 Ext. 3 Minimum Reference 0.000 ExtPID3Unit All set-ups TRUE -3 Int32 XC-52 Ext. 3 Maximum Reference 100.000 ExtPID3Unit All set-ups TRUE -3 Int32
XC-53 Ext. 3 Reference Source [0] No function All set-ups TRUE - Uint8
XC-54 Ext. 3 Feedback Source [0] No function All set-ups TRUE - Uint8
XC-55 Ext. 3 Setpoint 0.000 ExtPID3Unit All set-ups TRUE -3 Int32
XC-57 Ext. 3 Reference [Unit] 0.000 ExtPID3Unit All set-ups TRUE -3 Int32
XC-58 Ext. 3 Feedback [Unit] 0.000 ExtPID3Unit All set-ups TRUE -3 Int32
XC-59 Ext. 3 Output [%] 0 % All set-ups TRUE 0 Int32
XC-6#
XC-60 Ext. 3 Normal/Inverse Control [0] Normal All set-ups TRUE - Uint8 XC-61 Ext. 3 Proportional Gain 0.01 N/A All set-ups TRUE -2 Uint16 XC-62 Ext. 3 Integral Time 10000.00 s All set-ups TRUE -2 Uint32
XC-63 Ext. 3 Differentation Time 0.00 s All set-ups TRUE -2 Uint16
XC-64 Ext. 3 Dif. Gain Limit 5.0 N/A All set-ups TRUE -1 Uint16
7.2.21 XC-## Ext. PID Closed Loop
AF-600 FP High Power Operating Instructions
145
7
