Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
AO-0# AO-00 Terminal X42/1 Mode [1] Voltage All set-ups TRUE - Uint8 AO-01 Terminal X42/3 Mode [1] Voltage All set-ups TRUE - Uint8
AO-02 Terminal X42/5 Mode [1] Voltage All set-ups TRUE - Uint8
AO-1# AO-10 Terminal X42/1 Low Voltage 0.07 V All set-ups TRUE -2 Int16 AO-11 Terminal X42/1 High Voltage 10.00 V All set-ups TRUE -2 Int16
AO-14 Term. X42/1 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
AO-15 Term. X42/1 High Ref./Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
AO-16 Term. X42/1 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
AO-17 Term. X42/1 Live Zero [1] Enabled All set-ups TRUE - Uint8
AO-2#
AO-20 Terminal X42/3 Low Voltage 0.07 V All set-ups TRUE -2 Int16 AO-21 Terminal X42/3 High Voltage 10.00 V All set-ups TRUE -2 Int16 AO-24 Term. X42/3 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
AO-25 Term. X42/3 High Ref./Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
AO-26 Term. X42/3 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
AO-27 Term. X42/3 Live Zero [1] Enabled All set-ups TRUE - Uint8
AO-3# AO-30 Terminal X42/5 Low Voltage 0.07 V All set-ups TRUE -2 Int16 AO-31 Terminal X42/5 High Voltage 10.00 V All set-ups TRUE -2 Int16
AO-34 Term. X42/5 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
AO-35 Term. X42/5 High Ref./Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
AO-36 Term. X42/5 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
AO-37 Term. X42/5 Live Zero [1] Enabled All set-ups TRUE - Uint8
AO-4#
AO-40 Terminal X42/7 Output [0] No operation All set-ups TRUE - Uint8 AO-41 Terminal X42/7 Min. Scale 0.00 % All set-ups TRUE -2 Int16 AO-42 Terminal X42/7 Max. Scale 100.00 % All set-ups TRUE -2 Int16
AO-43 Terminal X42/7 Bus Control 0.00 % All set-ups TRUE -2 N2
AO-44 Terminal X42/7 Timeout Preset 0.00 % 1 set-up TRUE -2 Uint16
AO-5#
AO-50 Terminal X42/9 Output [0] No operation All set-ups TRUE - Uint8 AO-51 Terminal X42/9 Min. Scale 0.00 % All set-ups TRUE -2 Int16 AO-52 Terminal X42/9 Max. Scale 100.00 % All set-ups TRUE -2 Int16
AO-53 Terminal X42/9 Bus Control 0.00 % All set-ups TRUE -2 N2
AO-54 Terminal X42/9 Timeout Preset 0.00 % 1 set-up TRUE -2 Uint16
AO-6#
AO-60 Terminal X42/11 Output [0] No operation All set-ups TRUE - Uint8 AO-61 Terminal X42/11 Min. Scale 0.00 % All set-ups TRUE -2 Int16 AO-62 Terminal X42/11 Max. Scale 100.00 % All set-ups TRUE -2 Int16
AO-63 Terminal X42/11 Bus Control 0.00 % All set-ups TRUE -2 N2
AO-64 Terminal X42/11 Timeout Preset 0.00 % 1 set-up TRUE -2 Uint16
7.2.10 AO-## Analog I/O Option
AF-600 FP High Power Operating Instructions
132
