Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
E-0# E-00 Digital I/O Mode [0] PNP - Active at 24V All set-ups FALSE - Uint8 E-01 Terminal 18 Digital Input [8] Start All set-ups TRUE - Uint8
E-02 Terminal 19 Digital Input [0] No operation All set-ups TRUE - Uint8
E-03 Terminal 27 Digital Input null All set-ups TRUE - Uint8
E-04 Terminal 29 Digital Input [14] Jog All set-ups TRUE - Uint8
E-05 Terminal 32 Digital Input [0] No operation All set-ups TRUE - Uint8
E-06 Terminal 33 Digital Input [0] No operation All set-ups TRUE - Uint8
E-1# E-10 Accel Time 2 ExpressionLimit All set-ups TRUE -2 Uint32 E-11 Decel Time 2 ExpressionLimit All set-ups TRUE -2 Uint32
E-2#
E-20 Terminal 27 Digital Output [0] No operation All set-ups TRUE - Uint8 E-21 Terminal 29 Digital Output [0] No operation All set-ups TRUE - Uint8 E-24 Function Relay null All set-ups TRUE - Uint8
E-26 On Delay, Relay 0.01 s All set-ups TRUE -2 Uint16
E-27 Off Delay, Relay 0.01 s All set-ups TRUE -2 Uint16
E-5#
E-51 Terminal 27 Mode [0] Input All set-ups TRUE - Uint8 E-52 Terminal 29 Mode [0] Input All set-ups TRUE - Uint8 E-53 Terminal X30/2 Digital Input [0] No operation All set-ups TRUE - Uint8
E-54 Terminal X30/3 Digital Input [0] No operation All set-ups TRUE - Uint8
E-55 Terminal X30/4 Digital Input [0] No operation All set-ups TRUE - Uint8
E-56 Term X30/6 Digi Out (OPCGPIO) [0] No operation All set-ups TRUE - Uint8
E-57 Term X30/7 Digi Out (OPCGPIO) [0] No operation All set-ups TRUE - Uint8
E-6#
E-60 Term. 29 Low Frequency 100 Hz All set-ups TRUE 0 Uint32 E-61 Term. 29 High Frequency 100 Hz All set-ups TRUE 0 Uint32 E-62 Term. 29 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
E-63 Term. 29 High Ref./Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
E-64 Pulse Filter Time Constant #29 100 ms All set-ups FALSE -3 Uint16
E-65 Term. 33 Low Frequency 100 Hz All set-ups TRUE 0 Uint32
E-66 Term. 33 High Frequency 100 Hz All set-ups TRUE 0 Uint32
E-67 Term. 33 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
E-68 Term. 33 High Ref./Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
E-69 Pulse Filter Time Constant #33 100 ms All set-ups FALSE -3 Uint16
7.2.3 E-## Digital In/Outs
AF-600 FP High Power Operating Instructions
123
7
