Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
CL-0# CL-00 Feedback 1 Source [2] Analog input 54 All set-ups TRUE - Uint8 CL-01 Feedback 1 Conversion [0] Linear All set-ups FALSE - Uint8
CL-02 Feedback 1 Source Unit null All set-ups TRUE - Uint8
CL-03 Feedback 2 Source [0] No function All set-ups TRUE - Uint8
CL-04 Feedback 2 Conversion [0] Linear All set-ups FALSE - Uint8
CL-05 Feedback 2 Source Unit null All set-ups TRUE - Uint8
CL-06 Feedback 3 Source [0] No function All set-ups TRUE - Uint8
CL-07 Feedback 3 Conversion [0] Linear All set-ups FALSE - Uint8
CL-08 Feedback 3 Source Unit null All set-ups TRUE - Uint8
CL-1# CL-12 Reference/Feedback Unit null All set-ups TRUE - Uint8 CL-13 Minimum Reference/Feedb. 0.000 ProcessCtrlUnit All set-ups TRUE -3 Int32
CL-14 Maximum Reference/Feedb. 100.000 ProcessCtrlUnit All set-ups TRUE -3 Int32
CL-2# CL-20 Feedback Function [3] Minimum All set-ups TRUE - Uint8 CL-21 Setpoint 1 0.000 ProcessCtrlUnit All set-ups TRUE -3 Int32
CL-22 Setpoint 2 0.000 ProcessCtrlUnit All set-ups TRUE -3 Int32
CL-23 Setpoint 3 0.000 ProcessCtrlUnit All set-ups TRUE -3 Int32
CL-3#
CL-30 Refrigerant [0] R22 All set-ups TRUE - Uint8 CL-31 User Defined Refrigerant A1 10.0000 N/A All set-ups TRUE -4 Uint32 CL-32 User Defined Refrigerant A2 -2250.00 N/A All set-ups TRUE -2 Int32
CL-33 User Defined Refrigerant A3 250.000 N/A All set-ups TRUE -3 Uint32
CL-6# CL-7# CL-70 Closed Loop Type [0] Auto 2 set-ups TRUE - Uint8 CL-71 PID Performance [0] Normal 2 set-ups TRUE - Uint8 CL-72 PID Output Change 0.10 N/A 2 set-ups TRUE -2 Uint16
CL-73 Minimum Feedback Level -999999.000 ProcessCtrlUnit 2 set-ups TRUE -3 Int32
CL-74 Maximum Feedback Level 999999.000 ProcessCtrlUnit 2 set-ups TRUE -3 Int32
CL-79 PID Autotuning [0] Disabled All set-ups TRUE - Uint8
CL-8# CL-81 PID Normal/ Inverse Control [0] Normal All set-ups TRUE - Uint8 CL-82 PID Start Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
CL-83 PID Start Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
CL-84 On Reference Bandwidth 5 % All set-ups TRUE 0 Uint8
CL-9#
CL-91 PID Anti Windup [1] On All set-ups TRUE - Uint8 CL-93 PID Proportional Gain 0.50 N/A All set-ups TRUE -2 Uint16 CL-94 PID Integral Time 20.00 s All set-ups TRUE -2 Uint32
CL-95 PID Differentiation Time 0.00 s All set-ups TRUE -2 Uint16
CL-96 PID Diff. Gain Limit 5.0 N/A All set-ups TRUE -1 Uint16
7.2.20 CL-## PID Closed Loop
AF-600 FP High Power Operating Instructions
144
7
