3.1.12 Fuses
Branch circuit protection:
In order to protect the installation against electrical and fire hazard, all branch circuits in an installation, switch gear, machines etc., must be short-circuited and
over-current protected according to national/international regulations.
Short-circuit protection:
The frequency converter must be protected against short-circuit to avoid electrical or fire hazard. GE recommends using the fuses mentioned below to protect
service personnel and equipment in case of an internal failure in the drive. The frequency converter provides full short-circuit protection in case of a short-circuit
on the motor output.
Over-current protection
Provide overload protection to avoid fire hazard due to overheating of the cables in the installation. Fuses or circuit breakers can be used to provide the over-
current protection in the installation. Over-current protection must always be carried out according to national regulations.
3.1.13 Fuse tables
380-480 V, frame sizes 4X, 5X and 6X
The fuses below are suitable for use on a circuit capable of delivering 100,000 Arms (symmetrical), 480V/600V depending on the drive voltage rating. With the
proper fusing the drive Short Circuit Current Rating (SCCR) is 100,000 Arms.
AF-600
FP
Bussmann
E1958
JFHR2**
Bussmann
E4273
T/JDDZ**
SIBA
E180276
RKI/JDDZ
LittelFuse
E71611
JFHR2**
Ferraz-
Shawmut
E60314
JFHR2**
Bussmann
E4274
H/JDDZ**
Bussmann
E125085
JFHR2*
Internal
Option
Bussmann
150 HP FWH-
300
JJS-
300
2028220-
315
L50S-300 A50-P300 NOS-
300
170M3017 170M3018
200 HP FWH-
350
JJS-
350
206xx32-
315
L50S-350 A50-P350 NOS-
350
170M3018 170M3018
250 HP FWH-
400
JJS-
400
206xx32-
400
L50S-400 A50-P400 NOS-
400
170M4012 170M4016
300 HP FWH-
500
JJS-
500
206xx32-
500
L50S-500 A50-P500 NOS-
500
170M4014 170M4016
350 HP FWH-
600
JJS-
600
206xx32-
600
L50S-600 A50-P600 NOS-
600
170M4016 170M4016
Table 3.3: For Unit Sizes 41, 42, 43, and 44,380-480 V
AF-600 FP
Bussmann PN* Rating Ferraz Siba
450 HP 170M4017 700 A, 700 V 6.9URD31D08A0700 20 610 32.700
500 HP 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
550 HP 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
600 HP 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
Table 3.4: For Unit Sizes 51 and 52, 380-480 V
AF-600 FP
Bussmann PN* Rating Siba Internal Bussmann Option
650 HP 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
750 HP 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
900 HP 170M7082 2000 A, 700 V 20 695 32.2000 170M7082
1000 HP 170M7082 2000 A, 700 V 20 695 32.2000 170M7082
1200 HP 170M7083 2500 A, 700 V 20 695 32.2500 170M7083
1350 HP 170M7083 2500 A, 700 V 20 695 32.2500 170M7083
Table 3.5: Unit Sizes 61, 62, 63, and 64, 380-480 V
AF-600 FP
Bussmann PN* Rating Siba
650 HP 170M8611 1100 A, 1000 V 20 781 32.1000
750 HP 170M8611 1100 A, 1000 V 20 781 32.1000
900 HP 170M6467 1400 A, 700 V 20 681 32.1400
1000 HP 170M6467 1400 A, 700 V 20 681 32.1400
1200 HP 170M8611 1100 A, 1000 V 20 781 32.1000
1350 HP 170M6467 1400 A, 700 V 20 681 32.1400
Table 3.6: Unit Sizes 61, 62, 63, and 64, Inverter module DC Link Fuses, 380-480 V
*170M fuses from Bussmann shown use the -/80 visual indicator, -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and amperage may be
substituted for external use
**Any minimum 480 V UL listed fuse with associated current rating may be used to meet UL requirements.
AF-600 FP High Power Operating Instructions
24
3
