GE
DRAFT
LOGIQ P9/P7
D
IRECTION
5604324
, R
EVISION
11
DRAFT
(J
ANUARY
24, 2019
)
S
ERVICE
M
ANUAL
Chapter 8 -
Replacement Pr
ocedures
8-181
3)
Unscrew 7 screws to remo
ve the NEST EMI B
RKT and
pull out MIO ASSY from system.
4)
Unscrew 12 screw
s to remove the MIO BOX BRKT.
Figure 8-218 Unscrewing 7 screws to remove NEST
EMI BRKT and MIO
ASSY
Figure 8-219 Unscrewing 12 scre
ws to remove MIO BOX BRKT
506
508
