GEDRAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

Chapter 2 - Site Preparation 2-9

2-3-3-1 Recommended Ultrasound Room Layout

Figure 2-1 below shows a floor plan illustrating the recommended layout of the Ultrasound Room and

depicting the minimal room layout requirements.

Figure 2-1 Recommended Floor Plan 4.3m x 5.2m (14ft x 17ft)

35.5 IN.

(92 CM)

Dedicated Power Outlets

Hospital Network

Cabinet for

Software and Manuals

(optional)

LOGIQ P9/P7
