Chapter 9 - Renewal Parts 9-29

Section 9-11

Optional Peripherals and Accessories

9-11-1 Printers

NOTE: The illustrations may not correspond to the actual product!

Figure 9-16 Optional Peripherals and Accessories - Printers

Table 9-12 Optional Peripherals and Accessories - Printers

Item Part Name Part Number Description Qty FRU

811

Digital B/W Video Printer

(Sony UP-D898)

H46992LS Digital B/W Video Printer, USB-Port - 1
