GEDRAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

Chapter 9 - Renewal Parts 9-9

107-1

High Cabinet Dummy

Cover R3

5794085

Plastics, BW PRT Bezel, Dummy for

High Cabinets

11NNNY

108-1

Dummy Cover Set R3

S5794033

RS Dummy Cover, RS Lever Dummy

Cover, CWD Dummy Cover

11NNNY

109-1

Foot Cover Set R3

S5794020

Foot Cover Front, Foot Cover Rear

L,Foot Cover Rear R

11NNNY

110-1

ODD Dummy Cover R3

5794027 Plastic 1 1 N N N Y

Table 9-6 Plastic Covers (R3)

Item Part Name Part Number Description Qty FRU R1 R2 R2.5 R3
