GE LOGIQ P9 Service Manual

GEDRAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
Chapter 9 - Renewal Parts 9-15
Table 9-8 OPIO
Item Part Name
Part
Number
Description
Qty FRU R1 R2 R2.5 R3
301
LOGIQ P7 OPIO ASSY
S5503848
Full OPIO set, inclduing Main and Sub OPIO
sets for LOGIQ P7 (Different Emblem)
1 1 Y N N N
OPIO ASSY LOGIQ P7 SET
S5781418-2 OPIO ASSY LOGIQ P7 SET 1 1 Y Y Y N
302
OPIO ASSY LOGIQ P7 R3
7503848
Full OPIO set, inclduing Main and Sub OPIO
sets for LOGIQ P7 R3(Different Emblem)
1 1 N N N Y
303
LOGIQ P9 OPIO ASSY
S5603848
Full OPIO set, inclduing Main and Sub OPIO
sets for LOGIQ P9 (Different Emblem)
1 1 Y N N N
OPIO ASSY LOGIQ P9 SET
S5781419-2 OPIO ASSY LOGIQ P9 SET 1 1 Y Y Y N
304
OPIO ASSY LOGIQ P9 R3
7603848
Full OPIO set, inclduing Main and Sub OPIO
sets for LOGIQ P9 R3 (Different Emblem)
1 1 N N N Y
305
OPIO Main PWA Assy
5503847 OP Main PWA Assembly 1 1 Y N N N
306
LOGIQ P7/P9 OPIO 10.4 inch
LCD module set
5561038 Maru OPIO 10.4 LCD Set 1 1 Y N N N
307
LP7 Upper ASSY SET
S5781423
LP7 Upper ASSY SET
11YYYN
LP7 Upper ASSY SET
S5788926 1 1 Y Y Y N
307
LP9 Upper ASSY SET
S5781424 LP9 Upper ASSY SET 1 1 Y Y Y N
LP9 Upper ASSY SET R3
S6788927
LP9 Upper ASSY SET R3
1 1 N N N Y
308
LP7 Upper ASSY SET R3
S6788926 1 1 N N N Y
309
LP9 Upper ASSY SET R3
S6788927 LP9 Upper ASSY SET R3 1 1 N N N Y
310
Trackball Assy
5554918 Trackball Assy 1 1 Y N N N
311
LP7P9 OPIO Trackball with
cable - H
6554918-2 LP7P9 OPIO Trackball with cable - H 1 1 N Y Y Y
312
OPIO Button and Knob Sets
S5582808-2 OP Button+Knob sets 1 1 Y Y Y N
313
RS KNOB SET R3
S5794028 RS KNOB SET R3 1 1 N N N Y
314
OPIO Up/Down Button Sets
5582809
Up/Down Button, Rotation Button, OPIO
Dummy Button Sets
1 1 Y Y Y N
315
OPIO AN Key Gel Board
5503844 OPIO AN Key Gel Board 1 1 Y N N N
S5781421 LP7P9 OPIO ANKEY GEL BOARD PWA - H 1 1 N Y Y N
316
LP7P9 OPIO ANKEY GEL
BOARD PWA
7503844 LP7P9 OPIO ANKEY GEL BOARD PWA 1 1 Y Y Y N
317
LOGIQ P7 OPIO Plastic
Covers with Touch Screen
5582805 Full Cover set 1 1 Y Y Y N
LOGIQ P9 OPIO Plastic
Covers with Touch Screen
5582806 Full Cover set 1 1 Y Y Y N
318
OPIO LOWER COVER
5507036 OPIO LOWER COVER 1 1 Y Y Y N
319
OPIO Main PWA Assy
S5781422 OPIO Main PWA Assy 1 1 N Y Y Y
