5 - 40 Section 5-8 - Front End Processor (FEP)
5-8-4-6 LEDs
Figure 5-26 LEDs on the Relay board
Table 5-7 LEDs on the Relay board
LED NO. COLOR DESCRIPTION NORMAL OPERATION START UP ERROR CONDITION
DS1
GREEN
STATUS_LED
GREEN WHEN PROBE
PRESENT IN
CONNECTOR 4
DS2
GREEN
-5V AVEE LIT
DS3
GREEN
+12V LIT
DS4
GREEN
VCC LIT
DS5
GREEN
LVDC
GREEN WHEN PROBE
ACTIVE IN CONNECTOR 2,
3 OR 4
DS6
GREEN
+3V3 LIT
DS7
GREEN
DLP_AUX LIT
DS8, DS9, DS10, DS11 AND DS12 ARE DEBUG LEDS FOR PROBE CONNECTOR #4
