Page #327 background image
GE H
EALTHCARE
D
IRECTION
GA091568, R
EVISION
5 VIVID E9 S
ERVICE
M
ANUAL
Chapter 7 - Diagnostics / troubleshooting 7 - 17
7-9-3 XY Lock is not working
Follow the steps below to resolve this issue:
1.) Run the XYZ Test Program and select Fix Lock.
See: Section 7-8 "Motor Controller Test" on page 7-13.
2.) If the Lock still does not respond when pushing the buttons in front of the UI, release the Lock
manually.
See: 4-2-3-5 "Manually releasing the XY Lock" on page 4-12.
3.) Remove the Park Lock and adjust it manually.
See: 6-7-3-2 "XY Lock Adjustment for Lock and Brake Mechanism" on page 6-15.
7-9-4 XY Brake Motors Troubleshooting
NOTE: Cables are not labeled at the XY controller, so right side and left side motors are not defined.
When troubleshooting the XY brake motors, keep this in mind:
The rear motors are #1 and #3.
The front motors are #2 and #4.
Motor #1 and #2 are on the same side.
Motor #3 and #4 are on the same side (opposite to motor #1 and #2).
If you are in a silent environment, it may be possible to hear which motor is activated during the test.
7-9-5 Z Movement fails
If it is impossible to lower the Top Console, but moving it upwards, works OK, it indicates that one
of the control switches is stuck in “Up” position.
If you have to help the Top Console up when moving upwards, but the motor assistance work OK
when lowering the Top Console, it indicates that the gas spring inside the Z Mechanism is failing.
- Replace the Z Mechanism.
