GE H
EALTHCARE
D
IRECTION
GA091568, R
EVISION
5 VIVID E9 S
ERVICE
M
ANUAL
6 - 6 Section 6-4 - Backlight adjustment
6-4-4 Backlight and Blue Tint Adjustment
On the Utility screen - Page 1 of 2, you can adjust the Backlight and the Blue tint on the Main LCD
screen and the Backlight on the Touch Panel (TP).
• Adjust the left most rotary to adjust the LCD Backlight.
• Push and adjust the left most rotary to adjust the LCD Blue Tint.
• Adjust the second rotary from the left side, to adjust the Touch Panel (TP) Backlight.
6-4-5 Adjust LCD Brightness and Contrast
Select Page 2 of 2 on the Utility screen.
• Adjust the left most rotary to adjust the Main LCD’s Brightness.
• Push and adjust the left most rotary to adjust the Main LCD’s Contrast.
Figure 6-6 Utility screen - page 1
Figure 6-7 Adjust LCD Brightness and Contrast
