GE H
EALTHCARE
D
IRECTION
GA091568, R
EVISION
5
VIVID
E9 S
ERVICE
M
ANUAL
Chapter 5 - Component
s
and functions (theor
y)
5 - 73
5-9-14-12
Test Points on BEP5
Power Sup
ply
Several Test Poin
ts are availa
ble thro
ugh cut-outs in the BEP Power supply.
NOTICE
Be careful so you don’t short-circuit the
signals when placing the test pr
obe(s).
Figure 5-53
T
est
Points
on BEP5 Power Supply
T
able 5-22
T
est
Points
Test Point
COMMENTS
48V
AGND
Analog Ground
ACC3V3
SDA
ND SCL
PSON
PWR OK
-12V
3.3V
5V
12V
-2
12V
-1
48V OK
PGND
Power Ground
48V IN
FPO
PSON
5Vstdby
