GE H
EALTHCARE
D
IRECTION
GA091568, R
EVISION
5 VIVID E9 S
ERVICE
M
ANUAL
5 - 98 Section 5-12 - Peripherals overview
5-12-2-4 USB Hard Drive 2TB with RAID1
The Iomega Ultramax desktop hard drive is an external desktop hard drive, connected via USB to
either a Vivid E9 or an EchoPAC PC workstation. It is configured as RAID 1, so the content is mirrored
on two hard disk drives. Due to the RAID 1 mirroring, the unit can store maximum 1 TB of data.
The intended use for Iomega Ultramax desktop hard drive is for Disk Management.
NOTE:When Disk Management has been performed, it is recommended to backup the Patient Archive to a
medical grade DVD recordable disc (DVD-R).
NOTE:Only connect one USB storage device (like this Iomega Ultramax Desktop Hard Drive) to the Vivid
E9 or EchoPAC PC at a time.
NOTE:To be able to use an USB storage device (like this Iomega Ultramax Desktop Hard Drive) on a Vivid
E9, the Vivid E9 may need a BIOS upgrade. A CD with the new BIOS software is included in
the kit. Verification and installation instructions are included in the Iomega Ultramax Desktop
Hard Drive Installation Manual, Direction Number EY194147.
NOTE:To be able to use an USB storage device (like this Iomega Ultramax Desktop Hard Drive) on a PC
with EchoPAC SW Only, the user must log on with Administrator rights.
5-12-2-5 Ethernet
• Ethernet is connected to the I/O panel on the rear of the VIVID E9. Printers and external servers
may be available via the Ethernet network.
5-12-2-6 Network printers
For more information, see: 3-8-4-3 "External Peripherals (Optional) for Connection to Ethernet (TCP/IP
Network)" on page 3-37.
WARNINGWARNING
IF THE IOMEGA ULTRAMAX DESKTOP HARD DRIVE IS CONNECTED TO A VIVID E9,
ENSURE THAT IT IS PLACED OUTSIDE THE PATIENT VICINITY/PATIENT
ENVIRONMENT
