D IRECTION GA091568, R EVISION 5 VIVID E9 S ERVICE M ANUAL
8 - 42 Section 8-5 - Replacing Covers and Bumpers
8-5-3-2 Top Cover removal procedure
Follow these steps to remove the Top Cover:
1.) Remove two screws.
2.) Remove the Top Cover.
Figure 8-48 Top Cover fixing screws (seen from above)
REAR HANDLE

GE Vivid E9 Specifications

General

Power Requirements	100-240 VAC, 50/60 Hz
Display	High-resolution LCD monitor
Doppler Modes	Color Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
3D/4D Imaging	Yes
Advanced Features	Speckle Reduction Imaging
Connectivity	DICOM, USB, Ethernet
Transducer Types	Linear Array
Operating Temperature	10°C to 40°C
Humidity Range	30% to 80% non-condensing
