GE Vivid E9 Service Manual

GE H EALTHCARE
D IRECTION GA091568, R EVISION 5 VIVID E9 S ERVICE M ANUAL
1 - 4 Section 1-2 - Service manual overview
NOTE: When not otherwise specified, the contents in this manual applies to all VIVID E9 models.
GA000810
VIVID E9 100-230V 4D Expert Option
- 17” LCD
GA200824
VE9 Card Rack
Complete with
MLA16,
4D TEE backplane
and
192 RX channels
GB200001
BEP6 w/4D
v104.3.x
v110.1.12
v112.1.x
GA200890 or
GA200800
BEP5 w/4D
Nvidia
v110.1.x
GA200890 or
GA200800
BEP5 w/4D
Nvidia
v104.2.x
v104.1.x
v110.0.x
GA000815
VIVID E9 100-230V 4D Expert Option
- 19” LCD
GB200001
BEP6 w/4D
v104.3.x v110.1.12
v112.1.x
GA200890 or
GA200800
BEP5 w/4D
Nvidia
v104.3.2 v110.1.x
GA200890 or
GA200800
BEP5 w/4D
Nvidia
v104.3.2 v110.1.x
GA200890 or
GA200800
BEP5 w/4D
Nvidia
v104.2.x
v104.1.x
v110.0.x
GA000830
VIVID E9 100-230V 2D - 17” LCD
GA200804
VE9 Card Rack
Complete w. MLA4
GB200002
BEP6 wo/4D
v104.3.x
v110.1.12
v112.1.x
GA200900 or
GA200805
BEP5 wo/4D
v110.1.x
v104.2.x
v104.1.x
v110.0.x
GA000835
VIVID E9 100-230V 2D - 19” LCD
GB200002
BEP6 wo/4D
v104.3.x
v110.1.12
v112.1.x
GA200900 or
GA200805
BEP5 wo/4D
v110.1.x
v104.2.x
v104.1.x
v110.0.x
GA000100
VIVID E9, 100-230 VAC (with 4D)
GA200744
GA200890,
GA200800 or
5145000-10
BEP5 w/4D
v104.0.x v108.x.x
v112.1.x
GA200035
v112.1.x
NOTE!
Hardware
update or box
(console) swap
required.
Table 1-2 VIVID E9 Models and Hardware/Software Compatibility (cont’d) sheet 2 of 2
MODEL
NUMBER DESCRIPTION
FRONT END
PROCESSOR
CARD RACK
BACK END
PROCESSOR
SYSTEM
SOFTWARE
VERSION(s)
APPLICATION
SOFTWARE
VERSION(S)
CAN BE
UPGRADED
TO
