9 Technical data
207723 rev 7
Gendex Dental Systems 111
9.3 Symbols that may appear in the unit
Name and address of the manufacturer
Serial number
Radiation warning
Dangerous voltage
On or enabled
Off or disabled
Exposure switch
Connector for exposure switch
Ethernet connector
Operating instructions
Refer to operating instructions for more
information.
The operating instructions can be supplied
electronically or in paper format.
Collision warning
Unit can collide with a seated patient when
driving the carriage downwards. Pay attention on
the unit movement.
Laser radiation (yellow label)
Attention,consult accompanying documents
Ground (Functional)
Approved: Laihonen Tuuli 2016-12-02 16:41
Reviewed: Nieminen Timo Antero 2016-12-02 15:31
Approved
See PDM system to determine the status of this document. Printed out: 2017-03-22 10:54:38
D507729, 7
Copyright © 2016 by PaloDEx Group Oy. All rights reserved.
