Gendex GXDP-700 User Manual

8 Calibration and adjustment
84 Gendex Dental Systems
207723 rev 7
8.2 Preparing for calibration
1. Close the head support and lock it in its upmost position.
2. Switch the PC and unit on.
3. PC: Open the dental imaging software and then open a
patient (card) and give it an identifiable name, for exam-
ple: calibration (refer to the user’s manual supplied with
the dental imaging software for more information).
4. PC: Click the image acquisition button to activate image
capture.
5. Touch the settings button on the touch screen display.
6. Select the Quality assurance button.
The calibration display appears.
Approved: Laihonen Tuuli 2016-12-02 16:41
Reviewed: Nieminen Timo Antero 2016-12-02 15:31
Approved
See PDM system to determine the status of this document. Printed out: 2017-03-22 10:54:38
D507729, 7
Copyright © 2016 by PaloDEx Group Oy. All rights reserved.
