3 Imaging programs
26 Gendex Dental Systems
207723 rev 7
3.2 Advanced Panoramic programs
Advanced Panoramic Programs can be accessed by going
to the LCD display and clicking on the tool tab in the lower
left corner. From the menu that appears, check the box
that says "Advanced PAN Mode," and then return to the
Pan tab. You will then see an additional set of advanced
panoramic programs. You can return to the basic set of
panoramic programs by selecting the tool tab and
removing the check mark from the Advanced PAN
Program box.
Select the patient size from the three icons at the top of the
LCD screen. From left to right, the icons represent large,
medium, and small-sized patients. The dose is increased
towards left and decreased towards right. Selecting
different size patient settings may also affect some
panoramic program trajectories or collimation settings, as
described in individual program descriptions.
Frontal Dentition: Magnification 1.25
The Frontal Dentition Program provides a vertically and
horizontally collimated panoramic image, approximately
50mm in length and centered on the anterior teeth. Typical
coverage will be the upper and lower dentition from canine
to canine.
Approved: Laihonen Tuuli 2016-12-02 16:41
Reviewed: Nieminen Timo Antero 2016-12-02 15:31
Approved
See PDM system to determine the status of this document. Printed out: 2017-03-22 10:54:38
D507729, 7
Copyright © 2016 by PaloDEx Group Oy. All rights reserved.
