9 Technical data
207723 rev 7
Gendex Dental Systems 121
9.7.1 Scatter radiation in panoramic
program
The radiation hitting the skull is 481.8mR with values 90kV,
13mA,16sec.
Test instrument is positioned at 50 cm distance from the
skull to measure the scattered radiation.
The following table shows the scatter radiation levels
measured with the test instrument
Height Left ear 45deg Nose 45deg Right ear
central beam 0.187mR 0.246mR 0.417mR 0.335mR 0.227mR
15cm up from
central beam
0.158mR 0.134mR 0.161mR 0.144mR 0.158mR
15cm down
from central
beam
0.171mR 0.202mR 0.275mR 0.248mR 0.204mR
Approved: Laihonen Tuuli 2016-12-02 16:41
Reviewed: Nieminen Timo Antero 2016-12-02 15:31
Approved
See PDM system to determine the status of this document. Printed out: 2017-03-22 10:54:38
D507729, 7
Copyright © 2016 by PaloDEx Group Oy. All rights reserved.
