Gendex GXDP-700 User Manual

5 Using the unit
207723 rev 7
Gendex Dental Systems 55
5.4 Cephalometric exposures
■ Lateral projections
■ PA projections
■ Carpus view (Not available in USA and Canada)
WARNING! Remove all calibration tools, Pan and 3D
patient positioning accessories before taking any
cephalomateric exposures!
5.4.1 General instructions
1. Move the ceph sensor to the ceph sensor holder.
2. PC: Open the viewing software, select a patient and
schedule acquisition.
3. Select CEPH tab at the touchscreen display.
4. Select the imaging program.
5. Set the kV and mA or
select the patient size
(small, medium, large).
Approved: Laihonen Tuuli 2016-12-02 16:41
Reviewed: Nieminen Timo Antero 2016-12-02 15:31
Approved
See PDM system to determine the status of this document. Printed out: 2017-03-22 10:54:38
D507729, 7
Copyright © 2016 by PaloDEx Group Oy. All rights reserved.
