5 Using the unit
68 Gendex Dental Systems
207723 rev 7
5.5.6 Stone model and radiographic guide scan
For scanning of stone models and radiographic guides, a
positioning plate is available for the system.
1. Scan the patient with an open bite by securing the bite
with cotton pads.
2. Install the positioning plate. Position stone model.
NOTICE! It is recommended to use a sponge or a foam
under radiographic guide during the scan.
3. Take scout image with default values. Correct position if
needed.
4. Select same resolution and parameters as in patient
scan.
NOTICE! Position the radiographic guide in similar
way.
Approved: Laihonen Tuuli 2016-12-02 16:41
Reviewed: Nieminen Timo Antero 2016-12-02 15:31
Approved
See PDM system to determine the status of this document. Printed out: 2017-03-22 10:54:38
D507729, 7
Copyright © 2016 by PaloDEx Group Oy. All rights reserved.
