MAINTENANCE AND ADJUSTMENT OF THE UTV
- 90 -
(11.5 kg/cm2, 163.57Psi)
Maximum: 1,480Kpa
(14.8 kg/cm2, 210.50Psi)
·Crank over the engine with the electric starter (be
sure the battery is fully charged) with the throttle
wide-open until the compression reading on the
gauge stabilizes.
NOTE:
When cranking the engine, ground the spark plug
lead to prevent sparking.
4. Install:
·spark plug
18 Nm-20Nm (1.8 m · kg, 13 ft · lb)
5. Lower the cargo bed.
CHECKING THE ENGINE OIL LEVEL
1. Place the vehicle on a level surface
2. Remove:
·driver seat
·passenger seat
·console
Refer to “SEATS” in chapter 5.
3. Check:
·engine oil level
Oil level should be between the maximum
②and minimum ③marks.
Oil level low
Add oil to the proper level.
NOTE:
Do not screw the dipstick ① in when checking
the oil level.
Recommended oil
Follow the left chart.
NOTE:
Recommended oil classification:
API Service “SE”, “SF”, “SG” type or equivalent
(e.g. “SF—SE—CC”, “SF—SE—SD” etc.)
NOTE:
Do not allow foreign material to enter the
crankcase.
