CHASSIS

- 242-

SUSPENSION

Front Swing Arm

No. Part Name Qty Remarks

Removing the front swing arm

Front shock absorber 2

Hexagon flange nut M10×1.25 2

Hexagon flange bolt M10×1.25×55 2

Hexagon flange nut M10×1.25 2

Front anti-roll bar 1

6 "U" type rubber bush Φ21-40

Press block, rear anti-roll bar 2

Hexagon flange bolt M8×22 4
