ENGINE
- 163 -
CRANKCASE AND MIDDLE DRIVEN SHAFT
No. Part Name Qty Remarks
Remove the crankcase and middle
drive shaft
Remove the parts in the order listed.
Crankcase separation
1 Right crankcase 1
2 Crankcase gasket 1
3 Dowel pin 2
4 Crankshaft 1
5 Shaft 2
6 Connection rod cover/rod bushing 2/4
7 Universal joint 1
8 Oil seal 1
9 Bearing retainer 2
10 Bearing seat dowel pin 2
