CHASSIS
- 183-
DIRECTION SYSTEM
Steering Wheel part
No. Part Name Qty Remarks
Removing the steering wheel
1
Socket hexagon screw M6×16 6
2
Steering wheel body 1
3
Hexagon flange nut M12×1.25 1
4
Nylon bush Φ11×Φ16×Φ23×11
2
5
Steering column 1
6
Hex flange step bolt M8×13-Φ12×12 2
7
Hexagon flange self-lock nuts M8 2
8
Steering rod 1
9 Hexagon flange bolt M6×25 1
