CHASSIS

- 270-

SEAT

No. Part Name Qty Remarks

Removing the seat

1 Safety belt assy 1

2 Back rest 2

3 Seat cushion 2

4 Seat connection assy 2

5 Socket hexagon screw M8×25 10

6 Washer Φ8×Φ16×1.6 10

7 Washer Φ8×Φ28×3 16

Slide rail （R）

Slide rail （L）

10 Socket hexagon screw M8×25 8

11 Seat mounting board 2
