MAINTENCE AND ADJUSTMENT OF THE UTV
- 93 -
CHASSIS
CLEANING THE AIR FILTER
NOTE:
There is a check hose â‘¡ at the bottom of the
air filter case. If dust and/or water collect in
this hose, clean the air filter element and air
filter case.
1. Remove:
·driver seat
·passenger seat
·console
·air filter case cover ③
Remove air filter:
â‘ air filter Holder
â‘¡ air filter check hose
â‘¢ air filter case cover
â‘£ air filter element
NOTE:
Never operate the engine with the air filter
element removed. This will allow unfiltered air to
enter, causing rapid wear and possible engine
damage. Additionally, operation without the
filter element will affect carburetor tuning with
subsequent poor performance and possible
engine overheating.
2. Check:
·air filter element
â‘ air filter frame
â‘¡ sponge material
â‘¢ element retaining plate
·Damaged
Replace.
3. Clean:
·air filter element
a. Wash the element gently, but thoroughly in
solvent.
