CHASSIS

- 193-

DISK BRAKE COMPONENTS

No. Part Name Qty Remarks

Removing brake components

Auxiliary bumper 1

Rear brake oil pipe 1

Clamp Ⅱ （L=250）

Rubber water pipe clip 1

Hexagon flange bolt M6×16 1

Hexagon flange bolt M6×30 2

Hexagon flange bolt M6×16 5

Oil pipe clip 5

Hexagon flange bolt M6×12 4

Oil pipe clip front disc brake 4
