ENGINE
- 168 -
OUTPUT SHAFT
No. Part Name Qty Remarks
Remove the output shaft Remove the parts in the order listed.
Middle drive gear
1 Left gear case cover 1
2 Drive shaft coupling 1
3 Drive shaft spring/bearing 1/1
4 Output shaft Y-1 1
5 Washer/collar 1/1
6 Washer/o-ring 1/1
7 Universal Joint A φ22 1/1
8 Fuel seal 1
9 Collar/o-ring 1/1
10 Rear drive bearing seat 1
