CHASSIS
- 256-
COOLING SYSTEM
Water And Oil Radiator
No. Part Name Qty Remarks
Removing the radiator
1
Screw hoop Φ12×20 12
2
Pressureproof rubber oil pipe A-860 1
3
Pressureproof rubber oil pipe A-1100 1
4
Oil cooling radiator assy 1
5
H-shaped rubber washer 4
6
M type clip , oil pipe 2
7
Front metal oil pipe 2
8
Pressureproof rubber oil pipe C-1280 1
