CHASSIS
- 263-
WATER PUMP
No. Part Name Qty Remarks
Removing the water pump
1 Clip 3
2 Water pipe 1
3 O-ring Φ27×2.5 1
4 Water outlet connector, cylinder 1
5 Save temperature 1
6 Bolt M6×50 2
7 Bolt M6×12 2
8 Washer Φ6×Φ10×1 2
9 Bolt M6×25 2
10 Thermostat cover 1
11 Washer Φ20.5×Φ30×1 1
12 Gasket 1
13 Water pipe 1
