SPECIFICATIONS
- 74-
Chassis tightening torques
Tightening torque
Part to be tightened
Thread
size
Nm m · kg ft · lb
Remarks
Rubber connecting bracket 1(or 2) and frame M10 52 5.2 37
Engine and Rubber connecting bracket 2 (front) M10 52 5.2 37
M6 10 1.0 7.2
Engine and Rubber connecting bracket 1 (rear) M8 33 3.3 24
M6 10 1.0 7.2
Rear upper arm and frame M10 45 4.5 32
Rear lower arm and frame M10 45 4.5 32
Rear knuckle and rear upper arm M10 45 4.5 32
Rear knuckle and rear lower arm M10 45 4.5 32
Rear shock absorber and frame M10 45 4.5 32
Rear shock absorber and rear lower arm M10 45 4.5 32
Rear Balancing pole and frame M8 32 3.2 23
ball head of Rear Balancing pole and Rear Balancing pole M10 56 5.6 40
ball head of Rear Balancing pole and rear lower arm M10 56 5.6 40
Differential gear case and frame M10 55 5.5 40
Differential gear case filler plug M14 23 2.3 17
Differential gear case drain plug M10 10 1.0 7.2
Universal joint yoke and drive pinion gear M14 62 6.2 45
Differential motor and differential gear case cover M8 13 1.3 9.4
Differential gear case cover and differential gear case M8 25 2.5 18
Rear driving axle gear case and frame M10 70 7.0 51
Rear driving axle gear case filler plug M20 23 2.3 17
Rear driving axle gear case drain plug M10 20 2.0 14
Ring gear bearing housing and final drive gear case M8 23 2.3 17
M10 40 4.0 29
Ring gear stopper nut M8 16 1.6 11
Bearing retainer and final gear pinion gear bearing housing
M65 170 17.0 125
Left-hand
threads
Coupling gear and final drive pinion gear M12 80 8.0 58
Front upper arm and frame M10 45 4.5 32
Front lower arm and frame M10 45 4.5 32
Front shock absorber and frame M10 45 4.5 32
Front shock absorber and front upper arm M10 45 4.5 32
Steering shaft assembly and steering Cross gimbal M8 22 2.2 16
Steering assembly and steering Cross gimbal M8 22 2.2 16
Steering assembly and frame M10 48 4.8 35
Steering shaft assembly and frame M8 21 2.1 15
Steering wheel and steering shaft assembly M12 35 3.5 25
Steering knuckle and front upper arm M12 30 3.0 22
Steering knuckle and front lower arm M12 30 3.0 22
Tie-rod locknut M12 40 4.0 29
Steering knuckle and tie-rod M12 39 3.9 28
Front lower arm protector board and front lower arm M6 7 0.7 5.1
Seat belt and frame M10 59 5.9 43
