Honeywell C300 User Manual

5. C300 Configuration Form Reference
5.1. C300 Controller Block
R500
April 2017
Series 8 C300 Controller User's Guide
Honeywell
101
Plain Text
Parameter Name
User
Configurable
Notes
FTE Interface B MAC
Address
MACADDRB
No
Identifies Ethernet MAC
Address of FTE Interface
B (Green Tree Port)
Redun. Interface
MAC Address
MACADDRR
No
Identifies Ethernet MAC
Address of Redundancy
Interface.
Note 1: IMAGEVER is also provided on the Main Tab; it is provided here with other version
information related to the C300.
FTE tab
The FTE tab contains statistics related to Fault Tolerant Ethernet (FTE) communications
and performance. The FTE tab features parameters associated with the MAC Address
Resolution Table (MART), which deals with on-line Media Access Control (MAC)
address mapping. Two separate MARTs are maintained - one for FTE nodes and one for
non-FTE nodes.
The following table summarizes the parameter data you can monitor on the FTE tab of
the configuration form for the selected C300 block.
Plain Text
Parameter Name
User
Configurable
Notes
FTE Mart Statistics
Address Count
FTEMARTADDRCOUN
T
No
Shows number of IP
addresses contained in
FTE MART.
Max Depth
FTEMARTMAXDEPTH
No
Shows maximum depth
that the FTE MART has
reached (largest number
of entries in table).
Average Depth
FTEMARTAVGDEPTH
No
Shows average depth of
FTE MART (average
number of entries in table).
Address Collisions
FTEMARTCOLLCOUN
T
No
Shows number of
collisions that have
occurred when hashing
the FTE MART.
