Honeywell C300 User Manual

R500
April 2017
Series 8 C300 Controller User's Guide
Honeywell
29
2. C300 Controller Planning and Design
2.6. Control network considerations
Series 8
Component
Description
Model Number
module.
Note: The C300 Controller IOTA supports
only one controller module.
FTE Cable
STP CAT5 Cable with RJ 45 connectors
for FTE connections.
2 m (6.5 ft)
(Y) = Yellow coded boots
(G) = Green coded boots
51305482-102 (Y)
513054820202 (G)
5 m (16 ft)
51305482-105 (Y)
513054820205 (G)
10 m (33 ft)
51305482-110 (Y)
513054820210 (G)
20 m (65.5 ft)
51305482-120 (Y)
51305482-220 (G)
Redundancy
Cable
STP CAT5 Cable with RJ 45 connectors
joining primary and secondary controllers.
51305482-xxx
IOLink Cable
Multidrop cable assemblies to connect the
I/O modules of a controller IOLink.
xxxxxxxx-xxx
Battery Cable
Multidrop twisted pair cable to connect
battery power to controllers.
xxxxxxxx-xxx
2.6 Control network considerations
In Experion LX system, the C300 Controller exists as a single node on a FTE network.
FTE is the only supported communication protocol for C300 Controllers with
Experion LX.
C300 Peer communication with Experion LX nodes
The C300 supports peer communications with the C300 Controller nodes in Experion LX
Release 500.
