NOTE: Hot-pluggable components are signified with red touch points.
The only hot-pluggable components are the hard disk drives:
Cold-Swappable Components
To remove and replace cold-swappable components (components that are neither hot-swappable
nor hot-pluggable), shut down the operating system and power off the server. For complete
instructions on shutting down the operating system and powering off the server, see Chapter 4
(page 87).
NOTE: Cold-swappable components are signified with blue touch points.
The following are cold-swappable components:
• Front bezel
• DVD drive
• DIMMs
• Single- or dual-core processors
• System battery
• SAS core I/O card
• PCIe expansion card (optional)
• Smart Array P400 controller (optional)
• I/O backplane assembly
• Power backplane
• Diagnostic board
• Fan / display board
• SAS backplane
• System board
Accessing a Rack Mounted Server
The server is designed for rack mounting. The following procedure explains how to gain access
to the HP Integrity rx2660 that is mounted in an approved rack. For rack installation instructions,
review the documentation in the universal rack-mounting kit included with your server.
WARNING! Ensure that all anti-tip features (front and rear anti-tip feet installed; adequate
ballast properly placed; and so on) are employed prior to extending the server out of the rack.
Extending the Server from the Rack
NOTE: Ensure that there is enough area (approximately 1.5 meters [4.5 ft.]) to fully extend the
server from the front of the rack to work on it.
To extend the server from the rack, follow these steps:
1. Flip out the two pull handles located on both ends of the front bezel. This allows the server
to slide out of the rack.
142 Removing and Replacing Server Components
