Huawei FusionServer Pro 2288X V5 User Manual

1.2 Physical Structure
Figure 1-2 Physical structure of a 2288X V5 with 12 x 3.5" drives (example)
1 I/O module 1 2 I/O module 2
3 PSUs 4 Chassis
5 I/O module 3 6 Supercapacitor holders
7 Air duct 8 Front-drive backplane
9 Fan module brackets 10 Fan modules
11 Front drives 12 Heat sinks
13 Memory modules 14 Processors
15 Cable organizers 16 TPM/TCM
17 Mainboard 18 Screw-in RAID controller
card
19 OCP 2.0 mezzanine cards - -
FusionServer Pro 2288X V5 Server
User Guide 1 Overview
Issue 04 (2020-06-05) Copyright © Huawei Technologies Co., Ltd. 2
