2. Connect the new SFP+ cable.
Remove the dust-proof cap on the port, and insert the cable connector into
the port. When you hear a "click" and the cable cannot be pulled out, the
connector is secured.
Figure 7-19 Connecting an SFP+ cable
Step 5 Check whether the new cable is properly connected.
Power on the device. Check whether the communication with the peer device is
normal by running the ping command.
● If yes, go to Step 7.
● If no, go to Step 6.
Step 6 If the peer device cannot be pinged, check whether the cable is intact or the
connector is securely connected.
● If yes, contact Huawei technical support.
● If no, replace the cable or insert the connector securely, and go to Step 5.
Step 7 Bind the new optical cable.
Bind the new optical cable in the same way as the existing optical cables. You can
also remove all existing cable ties and bind all optical cables again if necessary.
----End
7.2.6.5 Connecting a USB Device
Procedure
Step 1 Connect the USB device to a USB port of the server.
FusionServer Pro 2288X V5 Server
User Guide 7 Installation and Conguration
Issue 04 (2020-06-05) Copyright © Huawei Technologies Co., Ltd. 90
