2.5.3 Drive Indicators
SAS/SATA Drive Indicators
Figure 2-28 SAS/SATA drive indicators
Table 2-8 Description of SAS/SATA drive indicators
Activity Indicator
(Green)
Fault Indicator
(Yellow)
Description
Steady on O The drive is in position.
Blinking at 4 Hz O Data is being read or written normally,
or data on the primary drive is being
rebuilt.
Steady on Blinking at 1 Hz The drive is being located.
Blinking at 1 Hz Blinking at 1 Hz The data on the secondary drive is
being rebuilt.
O Steady on A member drive in the RAID array is
removed.
Steady on Steady on The drive is faulty.
NVMe Drive Indicators
Figure 2-29 NVMe drive indicators
● If the VMD function is enabled and the latest VMD driver is installed, the
NVMe drives support surprise hot swap.
FusionServer Pro 2288X V5 Server
User Guide 2 Hardware Description
Issue 04 (2020-06-05) Copyright © Huawei Technologies Co., Ltd. 30
