7.2.6.4 Connecting a Cable to an Optical Port
Procedure
Step 1 Determine the model of the new cable.
You can use an optical cable or an SFP+ cable to connect to the optical port.
Step 2 Number the new cable.
● The number of the new cable must be the same as that of the old one.
● Use the same type of labels for the optical cable.
– Record the name and number of the local device to be connected on one
side of the label, and those of the peer device on the other side.
– Attach the label 2 cm (0.79 in.) away from the end of the optical cable.
Step 3 Lay out the new cable.
● Lay out the new cable in the same way as the old one.
For example, if the old cable is laid out in
underoor cabling mode, so is the
new cable.
● Lay out optical cables or SFP+ cables in the cabinet based on installation
requirements.
You are advised to arrange cables in the same way as existing cables. Ensure
that cables are routed neatly and undamaged.
● Separate optical cables or SFP+ cables from power cables and signal cables
when laying out the cables.
● The minimum bend radius of an optical cable or SFP+ cables is 4 cm (1.57
in.).
● Ensure that optical cables or SFP+ cables are laid out for easy maintenance
and capacity expansion.
● Optical cables must be bound using cable ties. Ensure that:
– Optical cables are bound closely, neatly, and straight.
– Cable ties are in even distance and fastened properly.
Step 4 Connect the cable to an optical port.
● When you use an optical cable:
a. Remove the optical cable to be replaced.
b. Connect the new optical cable.
▪
Connect the new optical cable to the same port as the removed one.
▪
Connect the optical cable to the optical module securely.
i. Insert the optical module into the optical port. See (1) in Figure
7-17.
ii. Close the latch on the optical module to secure it. See (2) in Figure
7-17.
iii. Insert the optical cable into the optical module. See (3) in Figure
7-17.
FusionServer Pro 2288X V5 Server
User Guide 7 Installation and Conguration
Issue 04 (2020-06-05) Copyright © Huawei Technologies Co., Ltd. 88
