Step 3 Remove the TPM from the HFC. See step (2) in Figure 5-141.
Step 4 Place the removed TPM in an ESD bag.
----End
5.10.4 Installing a TPM or TCM
This topic describes how to install a trusted platform module (TPM) or trusted
cryptography module (TCM).
Scenarios
Install a TPM or TCM if:
● A TPM or TCM has failed.
● A TPM or TCM needs to be replaced with a new model.
A TPM and a TCM are similar in terms of appearance and replacement procedure. This topic
describes how to install a TPM.
Prerequisites
Conditions
● You have powered
o the RH8100 V3. For details, see 6.2 Powering O the
RH8100 V3. Then you have removed all power cables from the server.
● You have removed the High-performance Fusion Console (HFC) from the
RH8100 V3. For details, see 5.10.1 Removing an HFC.
Data
● You have obtained the cabinet number and chassis number of the RH8100 V3.
● You have located the RH8100 V3 based on the preceding information, and
labeled its panel to prevent misoperations.
● You have determined the position on the RH8100 V3 for installing a TPM.
Tools
● ESD gloves
● M3 Phillips screwdriver
● Packaging materials, for example, an ESD bag
Hardware
Spare TPM
Procedure
Step 1 Wear an ESD wrist strap or ESD gloves. For details, see 1 Safety Instructions.
Step 2 Take the spare TPM out of its ESD bag.
RH8100 V3 Server
User Guide 5 Removing and Installing Parts of the RH8100 V3
Issue 30 (2019-12-19) Copyright © Huawei Technologies Co., Ltd. 268
