Hypertherm SYNC Powermax 65 User Manual

Install and Set Up the Plasma Power Supply
2
48 810470 Operator Manual Powermax65/85/105 SYNC
Powermax65 SYNC systems
Table 3 – 65 A CSA
Table 4 – 65 A CE/CCC
Extension cord length
< 3 m
(< 10 ft)
3 m – 7.5 m
(10 ft – 25 ft)
7. 5 m – 15 m
(25 ft – 50 ft)
15 m – 30 m
(50 ft – 100 ft)
30 m – 45 m
(100 ft – 150 ft)
Input voltage (VAC) Phase Extension cord gauge
200 – 240 1
10 mm
2
(8 AWG)
10 mm
2
(8 AWG)
10 mm
2
(8 AWG)
16 mm
2
(6 AWG)
25 mm
2
(4 AWG)
480 1
4mm
2
(12 AWG)
4mm
2
(12 AWG)
4mm
2
(12 AWG)
6mm
2
(10 AWG)
6mm
2
(10 AWG)
200 – 240 3
6mm
2
(10 AWG)
6mm
2
(10 AWG)
6mm
2
(10 AWG)
10 mm
2
(8 AWG)
16 mm
2
(6 AWG)
400/480 3
4mm
2
(12 AWG)
4mm
2
(12 AWG)
4mm
2
(12 AWG)
4mm
2
(12 AWG)
4mm
2
(12 AWG)
600 3
4mm
2
(12 AWG)
4mm
2
(12 AWG)
4mm
2
(12 AWG)
4mm
2
(12 AWG)
4mm
2
(12 AWG)
Extension cord length
< 3 m
(< 10 ft)
3 m – 7.5 m
(10 ft – 25 ft)
7. 5 m – 15 m
(25 ft – 50 ft)
15 m – 30 m
(50 ft – 100 ft)
30 m – 45 m
(100 ft – 150 ft)
Input voltage (VAC) Phase Extension cord gauge
380 3 4 mm
2
4mm
2
4mm
2
4mm
2
4mm
2
400 3 4 mm
2
4mm
2
4mm
2
4mm
2
4mm
2
