Install and Set Up the Plasma Power Supply
2
50 810470 Operator Manual Powermax65/85/105 SYNC
Powermax105 SYNC systems
Table 7 – 200 V – 600 V CSA
Table 8 – 230 V – 400 V CE
Table 9 – 380 V CCC / 400 V CE
Extension cord length
< 3 m
(< 10 ft)
3 m – 7.5 m
(10 ft – 25 ft)
7. 5 m – 15 m
(25 ft – 50 ft)
15 m – 30 m
(50 ft – 100 ft)
30 m – 45 m
(100 ft – 150 ft)
Input voltage (VAC) Phase Extension cord gauge
200 – 240 3
16 mm
2
(6 AWG)
16 mm
2
(6 AWG)
16 mm
2
(6 AWG)
25 mm
2
(4 AWG)
35 mm
2
(2 AWG)
480 – 600 3
6mm
2
(10 AWG)
6mm
2
(10 AWG)
6mm
2
(10 AWG)
6mm
2
(10 AWG)
6mm
2
(10 AWG)
Extension cord length
< 3 m
(< 10 ft)
3 m – 7.5 m
(10 ft – 25 ft)
7. 5 m – 15 m
(25 ft – 50 ft)
15 m – 30 m
(50 ft – 100 ft)
30 m – 45 m
(100 ft – 150 ft)
Input voltage (VAC) Phase Extension cord gauge
230 3 16 mm
2
16 mm
2
16 mm
2
25 mm
2
25 mm
2
400 3 10 mm
2
10 mm
2
10 mm
2
10 mm
2
10 mm
2
Extension cord length
< 3 m
(< 10 ft)
3 m – 7.5 m
(10 ft – 25 ft)
7. 5 m – 15 m
(25 ft – 50 ft)
15 m – 30 m
(50 ft – 100 ft)
30 m – 45 m
(100 ft – 150 ft)
Input voltage (VAC) Phase Extension cord gauge
380 3 10 mm
2
10 mm
2
10 mm
2
10 mm
2
10 mm
2
400 3 10 mm
2
10 mm
2
10 mm
2
10 mm
2
10 mm
2
