Hypertherm SYNC Powermax 65 User Manual

Install and Set Up the Plasma Power Supply
2
Powermax65/85/105 SYNC Operator Manual 810470 53
Powermax105 SYNC systems
Generators used with the Powermax105 SYNC must meet the requirements in Table 12 and
Table 13.
Table 12 – Voltage requirements
Table 13 – Engine drive requirements
200 V – 600 V CSA 3-phase, 50 Hz/60 Hz, 200 VAC – 600 VAC
230 V – 400 V CE 3-phase, 50 Hz/60 Hz, 230 VAC – 400 VAC
380VCCC / 400 V CE 3-phase, 50Hz/60Hz, 380VAC / 400VAC
Engine drive rating
Plasma power supply output
current
Performance (arc stretch)
30 kW 105 A Full
22.5 kW – 25 kW 105 A Decreased
20 kW 85 A Full
15 kW 70 A Decreased
15 kW 65 A Full
12 kW 65 A Decreased
12 kW 40 A Full
8 kW 40 A Decreased
8 kW 30 A Full
