Install and Set Up the Plasma Power Supply
2
52 810470 Operator Manual Powermax65/85/105 SYNC
Powermax65 SYNC and Powermax85 SYNC systems
Generators used with a Powermax65 SYNC or Powermax85 SYNC must meet the requirements in
Table 10 and Table 11.
Table 10 – Voltage requirements
* A 4-wire 1-phase connection (for example, NEMA 14-50R) is necessary for some generators. In this
condition, use an adapter to connect the plasma power supply’s 3-wire power cord plug (NEMA 6-50P) to
the 4-wire connector on the generator. Refer to Install a 1-phase power cord (CSA systems only) (if
necessary) on page 47 for more information.
Table 11 – Engine drive requirements
CSA
1-phase: 50 Hz/60 Hz, 230 VAC / 240 VAC*
3-phase: 50 Hz/60 Hz, 200 VAC – 600 VAC
CE/CCC 3-phase: 50 Hz/60 Hz, 380 VAC / 400 VAC
Engine drive rating
Plasma power supply output
current
Performance (arc stretch)
20 kW 85 A Full
15 kW 70 A Decreased
15 kW 65 A Full
12 kW 65 A Decreased
12 kW 40 A Full
8 kW 40 A Decreased
8 kW 30 A Full
