13
OPTIONS
13-4
D
Detaching
1�
T
urn the t
ransce
iver upsidedown in the dire
ction
of the arr
ow and pull it out of the belt c
lip�
NOTE:
Hold the transceiver rmly when
removing the transceiver from the belt clip�
2�
Detach t
he batter
y pac
k� (p� 1
-3)
3�
Lif
t up the tab o
n the base clip (
q
)
, and then sli
de
the clip in t
he directi
on of the ar
row (
w
)�
q
w
Battery
pack
BE CAREFUL!
Do not break your ngernail.
MB-136
bel
t
clip
123
125
