8
MDC 1200 SYSTEM OPERATION
8-5
D Transmitting an MDC Radio Check call
An MDC Radio Check call enables the user to
determine whether the targeted station is turned ON,
within the communication range and on the channel,
without requiring any action from the targeted station
user�
(Menu > Signaling/Call > Call Menu)
1� Push [Menu] to display the Menu screen�
2� Push [P2 (Up)] or [P1 (Down)] to select “Signaling/
Call,” then
push [OK]�
Channel/Scan ►
Signaling/Call ►
Menu
3� Push [P2 (Up)] or [P1 (Down)] to select “Call
Menu,” then
push [OK]�
Call List Select ►
Call Menu ►
Signaling/Call
4� Push [P2 (Up)] or [P1 (Down)] to select a station
ID, then push [OK]�
✔ ID 1 ►
✔ ID A01 ►
Call Menu
5� Push [P2 (Up)] or [P1 (Down)] to select “Radio
Check,” then push [PTT] to transmit an MDC
Radio Check call�
✔ Radio Check
✔ Stun
Station 1
• “Success” is displayed when an acknowledgment is
received from the targeted station�
• “Failed” is displayed if an acknowledgment is not
received from the targeted station�
TIP: Push [Call Menu] to directly display the “Call
Menu” screen in step 4 above�
Transmitting a call
D Transmitting an MDC Stun call
An MDC Stun call remotely disables the transceiver�
(Menu > Signaling/Call > Call Menu)
1� Push [Menu] to display the Menu screen�
2� Push [P2 (Up)] or [P1 (Down)] to select “Signaling/
Call,” then
push [OK]�
Channel/Scan ►
Signaling/Call ►
Menu
3� Push [P2 (Up)] or [P1 (Down)] to select “Call
Menu,” then
push [OK]�
Call List Select ►
Call Menu ►
Signaling/Call
4� Push [P2 (Up)] or [P1 (Down)] to select a station
ID, then push [OK]�
✔ ID 1 ►
✔ ID A01 ►
Call Menu
5� Push [P2 (Up)] or [P1 (Down)] to select “Stun,”
then push [PTT] to transmit an MDC Stun call�
✔ Stun
✔ Revive
Station 1
• “Success” is displayed when an acknowledgment is
received from the targeted station�
• “Failed” is displayed if an acknowledgment is not
received from the targeted station�
TIP: Push [Call Menu] to directly display the “Call
Menu” screen in step 4 above�
